Product specifications
2JW1002
WiFi ISM Low Profile High Efficiency Antenna
General Specification
Frequency: 2.4-5.0GHz/WiFi/Sigfox/LoRa/LPWA/BT/ZigBee/RFID/ISM
Mounting: Connector Mount
Dimensions (mm): Ø 10 × 71
Operating temperature: -20 °C to +65 °C
Standard colors: Black / White
Antenna and electrical specifications
2.4/5.0 GHz ISM
Standards: WiFi, BT, ZigBee, ISM
Frequency: 2410-2490, 4920-5925
VSWR: ~1.8:1, ~2.8:1
Efficiency (%): ~59.0, ~45.0
Peak Gain (dBi): ~3.0, ~1.0
Impedance (Ohm): 50
Polarisation: Linear
Max. Input Power (W): 25
