Product specifications
YB-TG240320S25A-N-A1
2.4" IPS, Serial/Parallel, 550nits
General Specification:
Module Size: 42.0 (W) * 59.0 (H) * 2.1 (T) mm
Module Size(With FPC): 57.5 (W) * 59.0 (H) * 2.1 (T) mm
Display Size(Diagonal): 2.4 inch
Display Format: 240(RGB)*320 Pixels
Active Area: 36.72(W) * 48.96 (H) mm
Pixel Pitch: 0.153 * 0.153 mm
LCD Type: TFT (262K) / Transmissive / Normally Black
View Angle: Free (IPS)
Controller IC: ILI9341V
Interface: Serial / Parallel
Brightness: 550 nits
Weight: 10.8g
