Product specifications
YB-TG480272C52A-C-A0
4.3" IPS with Touch, Parallel ,830nits
General Specification
Module Size: 114.40(W) * 76.10(H) * 4.00(T) mm
Display Size(Diagonal): 4.3 inch
Display Format: 480(RGB)* 272 Pixels
Active Area: 95.04(W) * 53.856(H) mm
View Area: 96.04(W) * 54.856(H) mm
Pixel Pitch: 0.198*0.198 mm
LCD Type: TFT(16.7M) / Transmissive/Normally Black
The Viewing Direction: Free (IPS)
Controller IC: SC7283
TFT Interface: Parallel
Brightness: 830 nits
CTP IC: ILI2117A
CTP Interface: I2C
Weight(g):~50
