Product specifications
YB-TG800320S02A-N-A
6.5", Bar type TFT, Parallel, 330nits
General Specification
Module Size: 164.9 (W) * 72.456 (H) * 3.71(T) mm
Module Size(With FPC): 164.9 (W) * 152.616 (H) * 3.71(T) mm
Display Size(Diagonal): 6.5 inch
Display Format: 800(BGR) * 320 Pixels
Active Area: 153.84 (W) * 57.088 (H) mm
pixel Pitch: 0.1923 * 0.1784 mm
LCD Type: TFT(16.7M)/Transmissive/ Normal White
Viewing Direction (gray inversion): 6 O' clock
Best Viewing Direction: 12 O' clock
Source Drive IC: EK9716DB + EK73002AB or Compatible
Interface: Parallel
Brightness: 330 nits
Weight: TBD
