Product specifications
FSP090M Series
Model; FSP090M-DBA
Description;
This series of medical adapters are Class I design (with safety-protected earth) with IEC-320/C14 or IEC 320/C6 AC inlet. Maximum 90W continued output power at 40℃ operation temperature. High-efficiency features comply with US DOE requirements. All models meet EN 55011 conducted and radiated emission.
FEATURES
‧ Class I design safety standard compliance
‧ IEC60601-1 & IEC 62368-1
‧ Energy efficiency DOE Level VI
‧ No load power consumption ≦ 0.21W
‧ High altitude 5000M operation
‧ Compliant with RoHS requirement
‧ Meet EN55011
