EK86 - Evaluation Kit for the PA198
** This EK does NOT contain the actual amplifier device, so that needs to be ordered separately **
This easy-to-use kit provides a platform for the evaluation of linear power amplifier circuits using the PA198 high speed amplifier.
Efficient PCB layout allows for evaluation of maximum slew rate capability of the amplifier.
Critical connections for power supply bypassing, compensation and current limiting are pre-wiredthrough PCB trace.
Components that are not normally available in engineering labs are provided in the evaluation kit for convenience.
External connections to the evaluation kit can be made via the terminals at the edge of the circuit board.
These terminal pads are suitable for standard banana jacks or direct soldering of wires.
- APEX Microtechnology product -
