Product specifications
Quectel EM060K-GL- LTE-A Cat 6 M.2 Module
Quectel EM060K-GL is an LTE Advanced Category 6 module. Adopting the 3GPP Release 12 technology, the module supports a theoretical peak data rate of 300 Mbps in the downlink and a theoretical peak data rate of 50 Mbps in the uplink. Designed in M.2 form factor, the module is compatible with Quectel LTE-A Cat 6 module EM06 Series, Cat 12 modules EM12-G/ EM120K-GL/ EM121R-GL/ EM120R-GL, Cat 16 module EM160R-GL, and 5G modules RM500Q/RM502Q Series, which facilitates ustomers’ migration between different modules.
EM060K-GL is designed for the global market and nearly covers all the mainstream carriers worldwide. The module supports Qualcomm® IZat™ location technology gpsOne 9HT (GPS, GLONASS, BDS and Galileo). The integrated GNSS greatly simplifies product design, and provides quicker, more accurate and more dependable positioning capability.
A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB drivers for Windows, Linux, Android/optional built-in eSIM) extend the applicability of the module to a wide range of applications such as industrial routers, home gateways, set-top boxes, industrial laptops, consumer laptops, industrial PDAs, rugged tablet PCs, and digital signage, etc.
Key Features:
- LTE-A Cat 6 module with M.2 form factor
- Support DL 2 Carrier Aggregation and 64QAM
- Worldwide LTE-A and UMTS/HSPA+ coverage
- Built-in eSIM (optional), DSSA
- Low power mode
- Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environment
- MIMO technology meets demands for data rate and link reliability in modem wireless communication syste
Variants:
- EM06K-GL: Global
- EM06K-AE: EMEA, APAC (Excl. China/Japan), Brazil
