7" IPS TFT and 10.1" HD IPS TFT cover lens for E-Charger market - Yeebo Europe

February 28, 2023

Yeebo delivers Ultra-Bright TFT choices for EV Charger applications

In line with most outdoor devices incorporating a user interface display, EV chargers follow in the footsteps of digital signage for their use case. Regardless of the application, these rugged units must function day and night in any weather conditions, under sustained use and the occasional act of vandalism.

Designers keen to avoid navigating through a TFT selection process on their new outdoor application can take advantage of two advanced TFT displays from Yeebo, which combine performance with ease of use at a competitive price.

These outstanding displays specifically target EV charger stations; given their superior quality, they are also ideal for any outdoor applications, from vending machines to ticketing systems, from information kiosks to parking meters.

The YB-TG1280800S is a 10.1” HD IPS TFT boasting 2200 nit ultra-bright backlight and 1000:1 contrast for a colour-rich, all-round viewing experience under any lighting conditions. With a reduced ledge between the active area and outline dimensions and a slim profile of 4.4 mm, YB-TG1280800S maximises the user interface surface whilst accommodating tight mechanical requirements.

The YB-TG1024600S is a 7” IPS TFT delivering 1000 nit of brightness and a contrast ratio of 800:1 in an even slimmer profile of just 2.69 mm. To the user's choice, these TFTs can be equipped with either an optically bonded 8 mm thick cover lens or projected capacitive multi-touch, delivering an impressive IK08 impact protection rating according to EN62262 standard.

Both products carry a significant MTBF of 50,000 hours, ensuring reliability and longevity of operation. In addition to being available with a native LVDS interface, both display modules feature an optional onboard HDMI interface that simplifies integration with the user’s SBC.

Customers using ASUS® Tinker Board for their project development will be delighted to know that Yeebo’s evaluation kit easily interfaces to this powerful and versatile embedded system; they will benefit from evaluating these excellent TFT LCDs whilst virtually emulating their product at the same time.

Find here all TFT displays

Learn more about the ultra-bright TFTs for your next project
