Product specifications
Attend 122B-150A00
SO DIMM DDR3 Socket Vertical Type, 1.5V 204Pin 15.0H Type A, Beige Long Latch Tray
ELECTRICAL
Current Rating: 0.5A per pin
Voltage Rating: 25V AC/DC
Contact Resistance: 60mΩ
Insulation Resistance: 500MΩ
Dielectric Withstanding Voltage: 120VAC
MECHANICAL
Durability: 25 Cycle
Latch Retention Force: 8N/ Pos. Min.
ENVIRONMENTAL
Operating temperature range: -40°C~+85°C
Storage temperature range: -40°C~+85°C
SOLDER ABILITY
Recommended IR Reflow(Wave Soldering) Temperature: 255°C 10Sec
- Attend Technology product -
